To ensure your bike is assembled correctly and operates safely, please carefully review the following important instructions after receiving your bike.
Installation Guidelines & Important Notes
Before Installation
-
Please confirm that all accessories and parts are included.
-
Inspect the bike and packaging for any shipping damage before assembly.
-
If any parts are missing or damaged, please contact support before installation.
Note: Dual-motor e-bikes are shipped in two separate packages.
Front Wheel Installation
- Make sure the axle is fully aligned with the front fork before tightening.
- Tighten both side nuts/bolts evenly to keep the wheel centered.
- After installation, spin the wheel to ensure it rotates smoothly without rubbing.
Cable Safety Check
- Carefully check that the motor cable, controller cable, and brake cables do not touch the front wheel or tire.
- Improper cable routing may cause the wheel to rub and damage the wiring during riding.
Bolt Tightness Check
Before first use, please recheck and tighten all major bolts, including:
- Handlebar bolts
- Pedals
- Front wheel hardware
- Seat post / saddle bolts
Tool Usage Reminder
- Do not overtighten bolts using electric power tools.
- Excessive force may strip threads or damage components, making future maintenance difficult.
Need Help With Installation?
If you have any questions about the installation steps, please click here to access our after-sales support page and view the installation video for your specific model.
First-Time Operation Guide
Battery Charging
- Before first use, it is recommended to fully charge the battery.
- The battery may be charged while installed on the bike or removed from the frame.
If your bike includes a 2-in-1 charger, please click here to view the charger usage guide.
Important Charging Notice
- The battery power switch must be turned ON during charging, otherwise the battery will not charge.
- After charging is complete, turn the battery switch OFF before reinstalling it into the frame. This helps prevent spark/burn marks caused by contact points connecting under live power.
Starting the Bike
- All ANIIOKI e-bikes are equipped with a remote control.
- The bike can only be powered on using the remote.
- Press the ⚡ button twice to power on the bike.
If the bike does not turn on, please check whether the battery switch is turned on.
Riding Functions & Gear Selection
- Throttle function
- Brake function
- Display screen operation
- Lights / horn
Note: The front light must be activated by long-pressing the display power button or the “+” button (depending on display model).
Gear Selection
- Shift from P mode into 1–3 or 1–5 gear levels
- If the bike remains in P mode, the motor will not operate.
Special Note – AQ177 Single Motor Model:
- Only supports 1–3 gears
- Display parameters are not adjustable
AQ177 single motor models / A8 single motor models are limited to 20 mph by default. Please click here to follow the instructions to remove the speed limit.
Conclusion
This guide is designed to help you properly assemble and set up your new ANIIOKI e-bike upon delivery, ensuring safe and reliable operation. Before use, please complete the following steps in order: check all accessories, install the front wheel, tighten all bolts, charge the battery, and perform a basic functionality test. Pay special attention to cable routing and the condition of the braking system.
To start the bike, use the remote control to power it on, and make sure the battery switch is turned ON and the gear is switched from P mode to a riding gear. It is also recommended to test the brakes, throttle, display, and lights before your first ride.
If you encounter any issues, you can visit the after-sales support page to view installation videos or contact customer service for assistance. For safety, please perform a low-speed test ride first to ensure the bike is functioning properly before normal use.
